Shanghai, China
100, 000pieces/Month
L/C, T/T, Western Union, Paypal
HCH
Heater
Ceramic Heater
Tube Type Heat Exchanger
Plate Heat Exchanger
DXY
Wooden Box and Pallet or According to Your Demand
specifications as clients′ request
China
69039000
Ceramic Heating Equipment
Cordierite/Corundum Mullte/Mullite/Silicon Oxide
Rto
25holes, 40holes, 43holes, 50holes, 60holes
1320-1700
Regenerative Heat Exchanger
Product Description
| Index | Metric Unit | Value | British Unit | Value |
| Material Density | g/cm3 | 2.3-2.6 | Lb/ft3 | 151 |
| Average Linear Expansion (20-800) | 10-6/k-1 | <2.5 | ||
| Special Heat Capacity | KJ/Kg | 900-1200 | ||
| Heat Conductivity | W/MK | 1.8-3.0 | ||
| Maximum Application Temp. | ° C | 1350 | 2450 | |
| Acid resist strength wt.loss | % | <4 | ||
| Water Absorption | % | <5 | ||
| (mm) | Quantity of channels | Wall thickness(mm) | Channel Width(mm) | Surface area(m2/m3) | Void section (%) | Packaging density(kg/m3) | Weight per piece(kg) |
| 150*150*300 | 25*25 | 1.0 | 4.96 | 580 | 68 | 696 | 4.7 |
| 150*150*300 | 40*40 | 0.7 | 3.03 | 891 | 65 | 814 | 5.5 |
| 150*150*300 | 50*50 | 0.6 | 2.39 | 1090 | 63 | 903 | 6.1 |
| 150*150*300 | 60*60 | 0.5 | 1.99 | 1303 | 63 | 932 | 6.3 |
| 150*100*100 | 40*40 | 1 | 2.5 | 784 | 49 | 799 | 1.2 |
| 150*100*100 | 33*33 | 1.1 | 3.0 | 691 | 52 | 750 | 1.13 |
| 150*100*100 | 20*20 | 2.0 | 5.0 | 392 | 49 | 692 | 1.04 |
| 100*100*100 | 40*40 | 1.0 | 2.5 | 784 | 49 | 810 | 0.81 |
| 100*100*100 | 33*33 | 1.1 | 3.0 | 691 | 52 | 750 | 0.75 |
| 100*100*100 | 20*20 | 2.0 | 5.0 | 392 | 49 | 680 | 0.68 |
