100, 000pieces/Month
Wooden Box, Carton Box with Pallet
L/C, T/T, D/P, Western Union
HCF
Square, Circular, Triangular, Hexagonal, etc
100cpsi, 200cpsi, 300cpsi, etc
DXY
China
1580< Refractoriness< 1770
Long Time Materials
Refractory Material
Square, Circular, Triangular, etc
Mullite, Cordierite, High Alumina, etc
50*50, 40*40, 65*65, 50*75, etc
Product Description
| Item material | Al2O3 (%) | Hole type | Milli hole(μm) | Coefficient of Thermal Expansion (×10-6/celsius degree) | Softening temperature (celsius degree) | Max. Workingtemperature (celsius degree) | Compressive Strength (MPa) |
| Cordierite | 37 | Round, square and delthyrium | 2-3 | ≤1.8 | 1390 | 1350 | ≥12 |
| Mullite | 46 | 2-3 | ≤4.0 | 1550 | 1500 | ≥15 | |
| ZrO-Mullite | 70 | 2-3 | ≤5.5 | 1650 | 1580 | ≥15 | |
| ZrO-Corundum | 70 | 2-3 | ≤5.5 | 1700 | 1650 | ≥15 |
| size(mm) | Hole shape | Aperture (mm) | Hole quantity (PCS) | Cell-opening ratio (%) | Pieces per cube |
| 100×100×(20) | Square | 2.2×2.2 | 33×33=1089 | 52.70 | (5000) |
| 100×100×(20) | Square | 2.5×2.5 | 31×31=961 | 60.06 | (5000) |
| 100×100×(20) | Square | 3.0×3.0 | 24×24=576 | 51.84 | (5000) |
| 81×81×(12.5) | Square | 1.46×1.46 | 44×44=1936 | 62.89 | (12193) |
| 75×75×(15) | Square | 2.2×2.2 | 26×26=676 | 58.17 | (11852) |
| 75×75×(15) | Round | Φ2.5 | 492 | 42.94 | (11852) |
| 120×65×(20) | Square | 2.2×2.2 | 38×20=760 | 47.16 | (6410) |
| 100×65×(20) | Square | 2.2×2.2 | 33×21=693 | 51.6 | (7692) |
| 100×60×(12.5) | Square | 2.2×2.2 | 33×20=660 | 53.29 | (13333) |
| 100×50×(20) | Square | 1.6×1.6 | 50×24=1200 | 61.44 | (10000) |
| 66×66×(12.5) | Square | 1.2×1.2 | 42×42=1764 | 58.31 | (18365) |
| 66×66×(12.5) | Square | 1.46×1.46 | 37×37=1369 | 66.99 | (18365) |
| 66×66×(12.5) | Square | 2.2×2.2 | 26×26=676 | 75.11 | (18365) |
| 66×66×(12.5) | Round | Φ2.4 | 440 | 45.7 | (18365) |
| 60×60×(20) | Square | 1.6×1.6 | 29×29=841 | 59.80 | (13889) |
| 60×60×(15) | Square | 2.2×2.2 | 20×20=400 | 53.78 | (18519) |
| 55×55×(12.5) | Round | Φ2.3 | 367 | 50.41 | (26446) |
| 55×55×(12.5) | Square | 2.2×2.2 | 21×21=441 | 70.56 | (26446) |
| 55×55×(12.5) | Square | 1.15×1.15 | 37×37=1369 | 59.85 | (26446) |
| 50×50×(12) | Square | 2.2×2.2 | 19×19=361 | 69.89 | (33333) |
| 50×50×(12.5) | Round | Φ2.3 | 294 | 48.86 | (32000) |
| 40×40×(10) | Round | Φ2.2 | 172 | 40.86 | (62500) |
| 40×40×(10) | Square | 1.4×1.4 | 22×22=484 | 59.29 | (62500) |
| Φ90×(12.5) | Square | 2.2×2.2 | 696 | 52.95 | (12582) |
| Φ60×(10) | Square | 1.44×1.44 | 502 | 36.82 | (35368) |
| Φ52×(7) | Square | 2×2 | 234 | 44.07 | (67304) |
| Φ52×(7) | Square | 1.44×1.44 | 286 | 27.93 | (67304) |
| Φ50×(10) | Round | Φ2.3 | 109 | 23.06 | (50955) |
