| Quantity: | |
|---|---|
100, 000pieces/Month
Wooden Box, Carton Box with Pallet
L/C, T/T, D/P, Western Union
CHF
Square, Circular, Triangular, Hexagonal, etc
100cpsi, 200cpsi, 300cpsi, etc
DXY
China
1580< Refractoriness< 1770
Long Time Materials
Refractory Material
Square, Circular, Triangular, etc
Mullite, Cordierite, High Alumina, etc
50*50, 40*40, 65*65, 50*75, etc
Product Description
| Item material | Al2O3 (%) | Hole type | Milli hole(μm) | Coefficient of Thermal Expansion (×10-6/Degree C) | Softening temperature (Degree C) | Compressive Strength (MPa) |
| Cordierite | 34 | Round, square and delthyrium | 2~3 | ≤1.6 | 1390 | ≥12 |
| Mullite | 62-64 | 2~3 | ≤5.0 | 1600 | ≥15 | |
| Corundum-Mullite | 73-75 | 2~3 | ≤6.0 | 1700 | ≥15 |
| Size(mm) | Cell Diameter (mm) | Number of hole (PCS) | Cell-opening ratio (%) | Effective filter area |
| 40×40×10 | 1.44×1.44 | 484 | 62 | 1200 |
| 40×40×12 | 2.0×2.0 | 225 | 56 | 1200 |
| 50×50×12.5 | 2.0×2.0 | 400 | 64 | 1960 |
| 55×55×12.5 | 1.15×1.15 | 1369 | 59 | 2310 |
| 55×55×12.5 | 2.2×2.2 | 441 | 70 | 2310 |
| 60×60×20 | 2.2×2.2 | 400 | 54 | 2820 |
| 66×66×12.5 | 1.24×1.24 | 1681 | 60 | 3560 |
| 66×66×12.5 | 1.44×1.44 | 1225 | 59 | 3560 |
| 66×66×12.5 | 2.1×2.1 | 576 | 59 | 3560 |
| 75×75×15 | 2.2×2.2 | 676 | 59 | 4650 |
| 81×81×12.5 | 1.44×1.44 | 1932 | 61 | 5510 |
| 100×50×20 | 1.6×1.6 | 1200 | 62 | 4100 |
| 100×100×20 | 2.5×2.5 | 961 | 61 | 8500 |
| 150×100×22 | 2.5×2.5 | 1426 | 59 | 13250 |
| 150×150×22 | 3.0×3.0 | 1296 | 52 | 19600 |
