Shanghai, China
100, 000pieces/Month
L/C, T/T, Western Union, Paypal
DPF
100-600cpsi
as Catalyst Used in Diesel Engine
DXY
Wooden Box/Carton Box with Pallet
China
84213990
Ceramic
Euro IV
ISO9001, TS16949
Catalytic Converter
Cordierite, Sic
Oval, Round, Racetrack, etc
Product Description
Property (uncatalyzed) | 100/17 | 200/12 | |
Cell density | cpsi | 100 | 200 |
cpscm | 15.5 | 31.0 | |
Wall thickness | inch | 0.017 | 0.012 |
mm | 0.432 | 0.305 | |
Open frontal area (OFA), % | 34.5 | 34.5 | |
Geometric surface area (GSA) | Inch2 | 33.3 | 47.0 |
m2/l | 1.31 | 1.85 | |
Hydraulic diameter | Inch | 0.083 | 0.059 |
mm | 2.11 | 1.49 | |
Modulus of rupture (psi/cpscm) | 350 | 300 | |
Porosity (%) | 48 | 48 | |
Coefficient of thermal expansion 102 cm/cm/ (20-800) --maximum average | 5 | 5 | |
Mean pore size (micron) | 13 | 13 | |
Melting temperature (Degree C) | 1460 | 1460 |
Specification(mm) | Cells per square inch | Volume(litre) |
Φ144×150 | 100/200 | 2.4432 |
Φ144×152.4 | 100/200 | 2.4823 |
Φ150×150 | 100/200 | 2.6511 |
Φ190×200 | 100/200 | 5.6713 |
Φ190×203 | 100/200 | 5.7564 |
Φ228×305 | 100/200 | 12.4542 |
Φ240×240 | 100/200 | 10.8588 |
Φ240×305 | 100/200 | 13.7997 |
Φ286×305 | 100/200 | 19.5965 |
