Quantity: | |
---|---|
Shanghai, China
100, 000pieces/Month
L/C, T/T, Western Union, Paypal
DPF
100-600cpsi
as Catalyst Used in Automobile/Motorcycle
DXY
Wooden Box/Carton Box with Pallet
China
84213990
Catalytic Converter
Ceramic
Euro IV
ISO9001, TS16949
Catalytic Converter
Cordierite
Product Description
Item | Technical index | |
Chemical Composition | SiO2 | 50.9 ± 1% |
AL2O3 | 35.2 ± 1% | |
MgO | 13.9 ± 1% | |
Physical Properties | Compression Strength in normal temperature | ≥ 10Mpa |
Thermal expansion coefficient | ≤ 1.2 × 10-6 / ° C | |
Wall thickness of hole density of 100 hole/ in2 | 0.42-0.50mm | |
Wall thickness of hole density of 200 hole/ in2 | 0.32-0.40mm | |
Apparent porosity | ≥ 50% | |
Average hole diameter | 10-15 micron | |
Highest Working Temperature | 1400 ° C | |
Soot-filtration efficiency | ≥ 95% |
Shape | Hole density (hole/in2) | Size (mm) | Volume(litre) |
Round | 100/200 CPSI | Φ 127 x 152.4 | 1.9308 |
Round | 100/200 CPSI | Φ 144x150 | 2.4432 |
Round | 100/200 CPSI | Φ 144x152.4 | 2.4823 |
Round | 100/200 CPSI | Φ 144x254 | 4.1372 |
Round | 100/200 CPSI | Φ 150x150 | 2.6511 |
Round | 100/200 CPSI | Φ 190x200 | 5.6713 |
Round | 100/200 CPSI | Φ 190x203 | 5.7564 |
Round | 100/200 CPSI | Φ 190x305 | 8.6487 |
Round | 100/200 CPSI | Φ 228x305 | 12.4542 |
Round | 100/200 CPSI | Φ 240x100 | 4.5245 |
Round | 100/200 CPSI | Φ 240x240 | 10.8588 |
Round | 100/200 CPSI | Φ 240x305 | 13.7997 |
Round | 100/200 CPSI | Φ 260x305 | 16.1954 |
Round | 100/200 CPSI | Φ 267x305 | 17.0792 |
Round | 100/200 CPSI | Φ 286x267 | 17.1550 |
Round | 100/200 CPSI | Φ 286x305 | 19.5965 |
Round | 100/200 CPSI | Φ 286x355 | 22.8090 |
Round | 100/200 CPSI | Φ 286x381 | 24.4795 |
Race track | 100 CPSI | Φ 188x103x145 | 2.2055 |
Assemble track | 100 CPSI | Φ 374x270x317 | 27.0537 |
